A Universal Audio Apollo 16 is a professional rackmount Thunderbolt audio interface designed for high-end studio environments, offering premium AD/DA conversion, large multichannel I/O, and onboard UAD DSP for real-time plug-in processing.
Type
Audio Interface
Model
Apollo 16
Manufacturer
Universal Audio
Country of Manufacture
China
Era
Modern
Year of Introduction
2012 (original Thunderbolt version)
Controls
-
Monitor level knob
-
Meter select button
-
Clock rate button
-
Power switch
-
Front-panel LED input/output meters (1–16)
Input
-
16× balanced line-level inputs (DB-25)
-
Word Clock input
-
Thunderbolt connection
Output
-
16× balanced line-level outputs (DB-25)
-
Monitor outputs (XLR)
-
Word Clock output
-
Headphone output
Power Supply
-
Internal universal AC power supply (IEC mains)
Notable Features
-
High-channel-count 16-in / 16-out line-level interface
-
Thunderbolt connectivity for ultra-low-latency performance
-
Built-in UAD-2 DSP for real-time plug-in processing
-
Premium AD/DA converters used in professional studios
-
Large front-panel LED metering for all 16 channels
-
Designed for integration with large analog consoles and outboard gear
-
Expandable via multiple Apollo units for higher I/O counts
