Description

Bastl Instruments Little Nerd, $139!

The Bastl Instruments Little Nerd is a compact 6HP Eurorack module designed to process and manipulate clock, trigger, and gate signals within a modular synthesizer setup. It offers a versatile array of functions, making it an essential tool for complex rhythmic and timing applications.

Specifications:

  • Width: 6HP
  • Depth: 50mm
  • Power Consumption: +5V: 30mA
  • Inputs:
    • Input 1: Processes digital signals for clock, gate, or trigger manipulation.
    • Input 2: Accepts additional clock, gate, or trigger signals; can be combined with Input 1 based on probability settings.
  • Outputs:
    • Output 1-3: Provide processed signals from Input 1.
    • Output 4-5: Deliver processed signals from Input 2 or a combination of both inputs.
  • Country of Manufacture: Czech Republic

Functionality: The Little Nerd offers seven distinct programs to manipulate incoming signals:

  1. Delayed Divider: Combines clock division (divisors 1 to 8) with a clock delay offset.
  2. Trig2Gate: Converts triggers to gates with adjustable pulse width; includes a flop divider that toggles gate status with each clock.
  3. Multiplier: Classic clock multiplier with factors ranging from 1 to 8.
  4. Trigger Repeater: Repeats input pulses with configurable number and rate, ideal for creating rapid-fire drum patterns.
  5. Euclidean Sequencer: Generates 16-step sequences with individually adjustable length and fill parameters.
  6. Clock Oscillator: Produces a clock signal with adjustable pulse width, capable of reaching audio rates for unique modulation effects.
  7. Probability/Groove: Applies a probability factor to incoming triggers, allowing for randomized pattern variations; the groove setting introduces a delay to every second clock pulse for swing effects.

The module’s two sections can operate independently or in tandem. The second section features a “Probability Mix” control, determining the likelihood of processing signals from Input 1, Input 2, or a blend of both, enabling intricate and evolving rhythmic patterns.

Notable Features:

  • Versatility: Combines multiple clock and trigger processing functions in a single module.
  • Compact Design: Offers extensive functionality within a 6HP footprint, conserving valuable rack space.
  • User-Friendly Interface: Intuitive controls and clear program selection facilitate seamless integration into various setups.
